BDB-1340A W/ 203 DRO & CC by Jet - US

Call For Price

Part Number: JT9-321108
UPC:
Availability: Item is usually in stock, but we'll be in touch if there's a problem

Quantity:

Add To Cart

Add To Estimate

Add To Wishlist

Compare Item

Product Overview

JET Belt Drive Bench Lathes feature an enclosed gearbox with helical cut gears for noise reduction and smooth operation while the spindle is supported by precision tapered roller bearings. The full-length splash guard on all sizes prevents hot chips and fluid from contaminating the work area and the quick-change gearbox allows for fast and easy gear changes for metric threading. The JET Belt Drive Bench Lathe is shown with the optional bench designed for this machine. Each JET Lathe comes loaded with features you’ve come to expect, all backed by the industry leading JET Two Year Warranty.

Specifications

Details

Industrial Category:

Machining

Industrial Subcategory:

Milling

Accessory 2:

Collet Closer

Base Unit of Measure:

BOM Products:

JT9-321360A,JT9-321515A,JT9-T203-0840J

Carriage Travel (In.):

Commodity Code:

8458.19.0020

Compound Slide Travel (In.):

2-11/16

Drive:

Belt

Enabled:

Yes

End User Sellable:

Family:

Vises - Milling

Item Display Order:

194

Item Weight (kgs):

1190

Length of Gap (In.):

Magento Website Mapping:

JET Parts

Max Tool Size (In.):

5/8 x 5/8

Model Number:

BDB-1340A

Motor (HP):

2 HP, 230V, 1Ph

Number of Inch Threads:

Number of Longitudinal and Cross Feed Rates:

Number of Metric Threads:

Number of Spindle Speeds:

Old Item Number:

321108

Overall Dimensions (L x W / in.):

71 x 32 x 45

Range of Cross Feeds (IPR):

0.0006-0.013

Range of Inch Threads (TPI):

3-1/2 - 80

Range of Longitudinal Feeds (IPR):

0.0018-0.0374

Range of Metric Threads:

0.45-10

Range of Spindle Speeds (RPM):

60 - 1,240

Ready for Web:

Yes

Size:

13 x 40

Spindle Bore (In.):

1-3/8

Spindle Mount:

D1-4

Spindle Taper with Sleeve:

MT-5 (MT-3)

Steady Rest Capacity (In.):

2-5/8

Style (Type):

Bench

Swing Over Bed (In.):

Swing Over Cross Slide (In.):

7-25/32

Swing Through Gap (In.):

18-3/4

Tailstock Spindle Travel (In.):

3-3/4

Taper in Tailstock Spindle:

MT-3

Transportation:

LTL

UPC:

731325204339

Weight (Lbs.):

1175

Weight (Lbs.) (Unit):

Pound

Width of Bed (In.):

7-3/8

Manufactured By:

Jet - US

Other Details

6" 3-jaw direct mount scroll chuck with top reversing jaws

Automatic feeding and threading are fully interlocked

Carriage mounted spindle control lever

Centers and headstock center sleeves

Change gears to allow metric threading

Feed selectors travel in grooved ways

Independent lead screw and feed rod

Low voltage motor controls

Tailstock may be offset for turning taper

Tolerance test certificate included
